The following is a guest post by Gustav Andersson who has come up with a clever little technique for a text flow problem. I’ve struggled with this myself in the past, so I’m happy to add this technique to the ol’ toolbox. Not mention, yet another one of these.
An example where a floating image leaves only enough space for a very narrow column of text which looks ugly and is broken up be a long word.
An example where a floating image leaves a few orphaned words.

A floating image takes away horizontal space from the text that flows around it. In fixed width layouts, you can check that the space left for the text is enough to create a decent looking column, safe in the knowledge that everyone else will see the same thing.

In a fluid layout, however, you have no such guarantee. If a user views your site on a smaller device, the horizontal space left for the text may only fit a word or two per line. Such a narrow column of text doesn’t just look ugly; it is also brittle. A sentence containing a long word will split when the long word moves down below the floating image, leaving behind it dead empty space mid-sentence.

The elusive minimum paragraph width

To solve the problem of too narrow paragraphs, we need a way to implement a minimum paragraph width. If the space left by the floating image is below this width, then the whole paragraph moves down underneath the image.

Same example as above, but with a red border around the paragraph, showing that it extends behind the  image.
The red border is the boundary of the paragraph element.

Intuitively, the following CSS seems to fit the bill:

p {
  min-width: 10em;
  /* For demonstration */
  border: 1px solid red;
}

However, this has no effect. The image floats above the paragraph, and thus doesn’t reduce the paragraph’s ‘official’ width. Meanwhile, the text within the paragraph dutifully moves aside to make room for the floating image, and so the problem remains.

The media query solution for known image widths

An example showing how the media query has disabled the floating of the image, and the entire paragraph is underneath.
The Media Query solution works, but requires fixed-width images.

If your images (or other floating content) share a fixed and predefined width, then you can use CSS3 media queries to disable the floating at screen sizes that are too narrow to fit both an image and a text column side by side.

This solution will of course only work on browsers that support CSS media queries. For other browsers, the solution degrades to the original problem.

@media screen and (max-width: 400px) {
  img {
    float: none;
  }
}

General case solution using pseudo element

The media query solution doesn’t work when the floating elements have arbitrary widths, nor is it very elegant.

An example of the pseudo-element rule in place, showing a thin green border surrounding the pseudo element. Both the element and the paragraph are below the image.
This example shows the pseudo-element rule in place, showing a thin green border surrounding the pseudo element. Both the element and the paragraph are below the image.

A better solution is to give every paragraph an invisible CSS pseudo-element with the desired minimum paragraph width. If there isn’t enough space to fit this pseudo-element, then it will be pushed down underneath the image, taking the paragraph with it.

This solution is supported by most browsers. On older browsers, the solution degrades gracefully to the original problem.

p:before {
  content: "";
  width: 10em;
  display: block;
  overflow: hidden;
  /* For Demonstration */
  border: 1px solid green;
}

The pseudo element’s green border is there for demonstration purpose only. It is not required for the solution and you should remove it in your code. The pseudo element will then take no vertical space at all.

Demo & Download

View Demo   Download Files
